Fortpro

Product Data Sheet

Description

Fortpro M22 x 1.5 Metric Serrated Drive Wheel Studs F286686 specifically designed to provide a secure and reliable hold. With their design that combines a splined section on one end and an M22 x 1.5 metric thread on the other, these studs ensure a solid connection between wheels and wheel hubs. This ensures a strong hold and prevents loosening of the bolts, significantly improving the stability and safety of the vehicle.

Specification

  • Brand: Fortpro
  • Part Type: Wheel Stud / Metric Serrated Drive Wheel Stud
  • Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
  • Part OEM: E5997. E-5997
  • DIN / ISO Grade: 10.9
  • Type: Headed
  • Metric Thread Size: M22 X 1.5-6g
  • Body Length (E): 0.88"
  • Body Diameter (G): 0,900"
  • Length from Under Head (B): 3 21/32"
  • Head Diameter (F): 1.26"
  • Head Style: Round
  • Head Thickness: 0.39"
  • Thread (A): M22 x 1.5
  • Thread Diameter (H): 22.0 mm
  • Wheel End Thread Direction: RH (Right Hand)
  • Threads per Inch: 1.5 per mm
  • Thread Length (C): 2.45"
  • Serration: Serrated
  • Serration Length (D): 0.39"
  • Serration Diameter: 0.950"
  • Application:: Use E-6000A nut
  • VMRS: 018-003-009
  • Item Package Quantity: 10
  • Notes: Grade 10.9 is the metric equivalent of Grade 8

Cross-References

  • Automann: 2016132
  • BWP: M3201
  • Budd: 106216, 3018503
  • Dayton Parts Batco: 131581
  • Euclid: E5997. E-5997
  • Meritor: R005997
  • Navistar: IT5997
  • Sirco Brake: 335
  • Spicer: 501285
  • Trailmobile: 385997
  • World Truck: 15427002

Dimensions

Dimension Not Available.
